Nelissen – Products - GoyaBack
|Clay bricks||210x65x100 mm||58 tk/m²|
|Brick slips||210x65x20 mm||58 tk/m²|
|Brick slip corners||210x65x20x100 mm|
|Euro CE (EN 771-1)|
|Belgium BENOR (PTV 23-002)|
|Resilience category||Class T2|
|Scope category||Class R1|
This hand-moulded facing brick is made from Limburger löss clay from the Kesselt tableland in the valley of the Meuse and revalue with raw materials from the Volcanic Eifel.
The facade bricks (non-perforated) have ﬁ ve sand covered sides and one oblong groove. The structure looks rugged with ﬁ ne and irregular grooves in the sandy surface. The baking process takes place in a gas-heat- ed tunnel oven under slightly reduced atmosphere.
The brick has a beige-pink base, with the hues ranging from salmon-pink to yellow-beige, and with white, pink and dark grey shadings.
0,15 N/mm² if jointed
0,3 N/mm² thin layer cooled
|Reaction to fire||Euro class A1|
|Water absorption||< 17%|
|Primer for water absorption||2,5 kg/m².min|
|Water evaporation rate||5/10 (table value EN 1745)s|
|Total density||1540 kg/m³, D2|
|Purity||1600 kg/m³, D2|
|Freezing / Thawing Resistor||
F2, cold class D, respectively, BRL 1007
Highly frost resistant according to PTV 23-002
|Characteristic compression strength||20 N/mm² according to PTV 23-002|
